| Input Voltage |
DC |
5V/2.5A |
| |
|
AC 100-240V, 50/60Hz |
| Analogue Inputs |
SE RCA L/R |
2.0V nominal @ 0dBFS, 1MegOhm Zin |
| |
SE 3.5mm |
1.0V nominal @ 0dBFS, 1 MegOhm Zin |
| |
BAL 4.4mm |
4.0V nominal @ 0dBFS, 24kOhm Zin |
| Max Input Level |
SE RCA |
3.8V RMS |
| |
SE 3.5mm |
1.92V RMS |
| |
BAL 4.4mm |
7.4V RMS |
| Headphone Output Section |
|
|
| Output Impedance |
BAL 4.4mm HP |
<2 Ohms |
| |
SE 6.3mm HP |
<1 Ohm |
| Headphone Output (RMS) |
BAL 4.4mm |
>11.5V/2,000mW (@ 64 Ohms) |
| |
SE 6.35mm |
>7.2V/1,600mW (@ 32 Ohms) |
| Headphone Output (Max.) |
BAL 4.4mm |
>15.1V/385mW (@ 600 Ohms) |
| |
|
>6.2V/1,200mW (@ 32 Ohms) |
| |
SE 6.35mm |
>7.6V/98mW (@ 600 Ohms) |
| |
|
>7.2V/1,600mW (@ 32 Ohms) |
| xMEMS |
BAL 4.4mm |
>21Vpp, 22 Ohms, 11V DC bias |
| SNR |
BAL 4.4mm |
≥125dB (7.3V 4.4mm Input 0dB @ 600 Ohms) |
| |
SE 6.35mm |
≥122dB (1.9V Input 0dB @ 600 Ohms) |
| DNR |
BAL 4.4mm |
≥119dB(A) @ 0dBFS |
| |
SE 6.35mm |
≥119dB(A) @ 0dBFS |
| THD+N |
BAL 4.4mm |
<0.006% (@ 360 mW/2.4V 16 Ohms) |
| |
SE 6.35mm |
<0.006% (@ 100mW/1.27V 16 Ohms) |
| Line Output Section |
|
|
| Output Impedance |
|
<200 Ohms |
| Output Level |
|
4Vrms (0dB 200kOhm load) |
| SNR |
|
≥125dB (7.3V 4.4mm Input 0dB @ 200kOhm) |
| DNR |
|
≥119dB(A) |
| THD+N |
|
0.006% (0dB 200kOhm load) |
| General |
|
|
| Gain |
|
0dB, 6dB, 12dB, 18dB |
| Frequency Response |
|
10Hz-200kHz (-3dB) |
| Power Consumption |
No Signal |
~5W |
| |
Max Signal |
~13W |
| Dimensions |
|
158x117x35mm (6.2x4.6x1.4”) |
| Net Weight |
|
495g (1.09 lbs) |
